多功能音箱集成拓展坞功能 双HDMI输出
XF-A3101A
这款音频坞可用作多个端口中心和扬声器电话。它的紧凑设计在家庭办公室到小型聚会室中占用极少的空间。对于商务旅行，用户可以轻松地将音频坞放入包中并带到任何地方，赋予了任何地方的工作空间。
多通道集线器和扬声器电话：该音频坞配备会议控制和扬声器电话。
4个麦克风：4个麦克风提供自然的声音和减少背景噪音的功能。
HDMI连接器：可以连接双显示器。
蓝牙5.2或USB插入即可使用：提供高质量、清晰的音频。
|
|
XF-A3101A
这款音频坞可用作多个端口中心和扬声器电话。它的紧凑设计在家庭办公室到小型聚会室中占用极少的空间。对于商务旅行，用户可以轻松地将音频坞放入包中并带到任何地方，赋予了任何地方的工作空间。
多通道集线器和扬声器电话：该音频坞配备会议控制和扬声器电话。
4个麦克风：4个麦克风提供自然的声音和减少背景噪音的功能。
HDMI连接器：可以连接双显示器。
蓝牙5.2或USB插入即可使用：提供高质量、清晰的音频。
这款音频坞可用作多个端口中心和扬声器电话。它的紧凑设计在家庭办公室到小型聚会室中占用极少的空间。对于商务旅行，用户可以轻松地将音频坞放入包中并带到任何地方，赋予了任何地方的工作空间。
多通道集线器和扬声器电话：该音频坞配备会议控制和扬声器电话。
4个麦克风：4个麦克风提供自然的声音和减少背景噪音的功能。
HDMI连接器：可以连接双显示器。
蓝牙5.2或USB插入即可使用：提供高质量、清晰的音频。
数字信号处理技术：
|
General |
Product Dimensions |
L130.6×W130.6×H50(mm) |
|
|
Product Weights |
377g |
|
|
Packaging Dimensions |
L167×W97×H43(mm) |
|
|
Packaging Weights |
547g |
|
|
Operating Environment |
Temperature: 0 to 40 °C Humidity: 20 to 85% (no condensation) |
|
|
Storage Environment |
Temperature: -20 to +45 °C Humidity: 10 to 90% (no condensation) |
|
|
ESD Protection |
Contact discharge: ±4kV Air discharge: ±8kV |
|
|
Enclosure |
ABS+PC , Black, Silver |
|
|
Compatible app |
Compatible with video conferencing apps: Amazon Chime, BlueJeans, Cisco@, Facebook, Messenger, Google Meet, GoToMeeting, Microsoft Teams, Skype, Skype for business, Slack, Zoom, etc. |
|
|
Supported OS |
- Windows 11/ 10, /macOS, iOS, Android, or other systems with standard UAC drivers. - iPhone can only connect by Bluetooth, iPad can connect by Bluetooth and USB-C. Android can connect by Bluetooth or USB-C |
|
|
Power Sources |
USB bus power/ USB-C PD 100 W IN voltage: 5-20V，0-5A |
|
|
Max.Power Consumption |
10W |
|
|
Standby consumption |
<3W |
|
|
Bluetooth |
Version: 5.2 Connection distance: 10M Bluetooth name: A3101 |
|
|
Warranty |
12 Months |
|
Interface |
Upstream port |
1*USB-C connect to HOST devices |
|
|
HDMI |
2*HDMI2.0(4K/60Hz)，support MST,SST |
|
|
Peripheral ports |
2*USB-A Gen2(10Gbps) ，1*USB-C Gen2(10Gbps)， together 10W , |
|
|
RJ45 |
1000Mbps/100Mbps/10Mbps Ethernet |
|
|
Power Sources |
USB-C PD IN voltage: 5-20V，0-5A |
|
Button |
Touch Key
|
- Volume Up/Down , - Microphone Mute/ Unmute , - Hang on / off , - Bluetooth / USB mode switch. |
|
Audio |
Microphone |
4* Omni directional ECM Φ6mmx2.7mm , 360° coverage, Pickup Range: 4M, Frequency response: 20Hz-8KHz |
|
|
Speaker |
5W , Full-range speaker x 1 Volume: 85 dB SPL @ 1M Frequency Bandwidth : 150 Hz to 20,000 Hz |
|
|
Audio Processing |
AEC,ANR,AGC |
|
General |
Product Dimensions |
L130.6×W130.6×H50(mm) |
|
|
Product Weights |
377g |
|
|
Packaging Dimensions |
L167×W97×H43(mm) |
|
|
Packaging Weights |
547g |
|
|
Operating Environment |
Temperature: 0 to 40 °C Humidity: 20 to 85% (no condensation) |
|
|
Storage Environment |
Temperature: -20 to +45 °C Humidity: 10 to 90% (no condensation) |
|
|
ESD Protection |
Contact discharge: ±4kV Air discharge: ±8kV |
|
|
Enclosure |
ABS+PC , Black, Silver |
|
|
Compatible app |
Compatible with video conferencing apps: Amazon Chime, BlueJeans, Cisco@, Facebook, Messenger, Google Meet, GoToMeeting, Microsoft Teams, Skype, Skype for business, Slack, Zoom, etc. |
|
|
Supported OS |
- Windows 11/ 10, /macOS, iOS, Android, or other systems with standard UAC drivers. - iPhone can only connect by Bluetooth, iPad can connect by Bluetooth and USB-C. Android can connect by Bluetooth or USB-C |
|
|
Power Sources |
USB bus power/ USB-C PD 100 W IN voltage: 5-20V，0-5A |
|
|
Max.Power Consumption |
10W |
|
|
Standby consumption |
<3W |
|
|
Bluetooth |
Version: 5.2 Connection distance: 10M Bluetooth name: A3101 |
|
|
Warranty |
12 Months |
|
Interface |
Upstream port |
1*USB-C connect to HOST devices |
|
|
HDMI |
2*HDMI2.0(4K/60Hz)，support MST,SST |
|
|
Peripheral ports |
2*USB-A Gen2(10Gbps) ，1*USB-C Gen2(10Gbps)， together 10W , |
|
|
RJ45 |
1000Mbps/100Mbps/10Mbps Ethernet |
|
|
Power Sources |
USB-C PD IN voltage: 5-20V，0-5A |
|
Button |
Touch Key
|
- Volume Up/Down , - Microphone Mute/ Unmute , - Hang on / off , - Bluetooth / USB mode switch. |
|
Audio |
Microphone |
4* Omni directional ECM Φ6mmx2.7mm , 360° coverage, Pickup Range: 4M, Frequency response: 20Hz-8KHz |
|
|
Speaker |
5W , Full-range speaker x 1 Volume: 85 dB SPL @ 1M Frequency Bandwidth : 150 Hz to 20,000 Hz |
|
|
Audio Processing |
AEC,ANR,AGC |
Package Included
1*Audio Dock
1*100W 1M USB C TO C cable
1*Manual
